아두이노 나노 ESP32 정품 (ARDUINO NANO ESP32) [OPEN-ARD-080]

4.0 0리뷰
26,400
구매혜택:         적립 마일리지 : +26원 (상품 : 26원)
자체상품코드 OPEN-ARD-080
브랜드:      ARDUINO

수량:
총 상품금액(VAT 포함):   26,400
배송비:    3,000원 조건별배송 지역별추가배송비
택배
 /
방문 수령지 : 인천광역시 미추홀구 주염로73번길 54 제이원플렉스 631호
추천 상품
  • 4,000원
  • 3,100원
  • 564,300원
  • 900원
  • 1,400원
  • 13,200원
  • 103,500원
  • 483,600원
  • 21,500원
인기 판매
  • 상품정보
  • 상품리뷰 (0)
  • 상품문의 (0)
  • 배송/반품/교환안내





Overview

Introducing the Nano ESP32, a powerful addition to the Arduino ecosystem that brings the popular ESP32-S3 to the world of Arduino and MicroPython programming. Whether you're a beginner stepping into the world of IoT or MicroPython, or an advanced user looking to incorporate it into your next product, the Nano ESP32 is the perfect choice. It covers all your needs to kick-start your IoT or MicroPython project with ease.

Let's explore the key features of the Nano ESP32:

  • Tiny footprint: Designed with the well-known Nano form factor in mind, this board's compact size makes it perfect for embedding in standalone projects.
  • Wi-Fiᆴ and Bluetoothᆴ: Harness the power of the ESP32-S3 microcontroller, well-known in the IoT realm, with full Arduino support for wireless and Bluetoothᆴ connectivity.
  • Arduino and MicroPython support: Seamlessly switch between Arduino and MicroPython programming with a few simple steps. We even offer an introductory course for those new to the MicroPython world, find more information in the documentation page.
  • Arduino IoT Cloud compatible: Quickly and easily create IoT projects with just a few lines of code. Our setup takes care of security, allowing you to monitor and control your project from anywhere using the Arduino IoT Cloud app. (Available starting August 2023)
  • HID support: Emulate human interface devices, such as keyboards or mice, over USB, opening up new possibilities for interacting with your computer.

There are no more excuses to delay your exploration of IoT and MicroPython. The Nano ESP32 provides everything you need to start creating and discovering the endless possibilities.

Tech specs

Board Name Arduinoᆴ Nano ESP32 with headers
SKU ABX00083
Microcontroller u-bloxᆴ NORA-W106 (ESP32-S3)
USB connector USB-Cᆴ
Pins Built-in LED Pin 13
Built-in RGB LED pins 14-16
Digital I/O Pins 14
Analog input pins 8
PWM pins 5
External interrupts All digital pins
Connectivity Wi-Fiᆴ u-bloxᆴ NORA-W106 (ESP32-S3)
Bluetoothᆴ u-bloxᆴ NORA-W106 (ESP32-S3)
Communication UART 2x
I2C 1x, A4 (SDA), A5 (SCL)
SPI D11 (COPI), D12 (CIPO), D13 (SCK). Use any GPIO for Chip Select (CS)
Power I/O Voltage 3.3 V
Input voltage (nominal) 6-21 V
Source Current per I/O Pin 40 mA
Sink Current per I/O Pin 28 mA
Clock speed Processor up to 240 MHz
Memory ROM 384 kB
SRAM 512 kB
External Flash 128 Mbit (16 MB)
Dimensions Width 18 mm
Length 45 mm
